We are delivering solutions to treat surface and well water and with the objective to supply drinkable water to isolated communities and facilities. We focus on small and mid size settlements, resorts, farms and mines, with production capacity up to 10'000 l per day.
Our systems are built in containerized modules
Projects exceeding 50'000 l per hour will require extra engineering from
.
| Item | HI-UF-100 | HI-UF-2000 | HI-UF-5000 | HI-UF-50000 |
|---|---|---|---|---|
| Type | UF Filter | UF Filter | UF Filter | UF Filter |
| Usage | Potable water Production | Potable water Production | Potable water Production | Potable water Production |
| Prod Capacity l/h (m3/h) | 100 (0.1) | 2000 (2.0) | 5000 (5.0) | 50000 (50.0) |
| Max Hour / day | 24 | 24 | 24 | 24 |
| Pore size (um) | 0.01 | 0.01 | 0.01 | 0.01 | Filtering size | >2um (100%) | >2um (100%) | >2um (100%) | >2um (100%) | Max turbity (output) | 0.2 NTU | 0.2 NTU | 0.2 NTU | 0.2 NTU |
| Auto Cleaning) | 5 min / 3 h | 5 min / 3 h | 5 min / 3 h | 5 min / 3 h |
| Power Consumption | 1 kW | 1.8 kW | 2.0 kW | 10.0 kW |
| Automation | Operation and remote control | Operation and remote control | Operation and remote control | Operation and remote control |
UF is a modern, safe and compact technology allowing to filter matter from water in order to remove high molecular-weight substances, colloidal materials, and bacteria, organic and inorganic polymeric molecules.
UF membrane is self cleaned by a reverse flow applied a few minutes every hour. The Filter should be cleaned or changed every year.
The maintenance of the system is therefore simple and can be done even in remote areas in Frontier countries.
Additionnal Disinfection is being done by ultraviolet (UV) or chlorination unit.
Energy saving,
Backwashable
Low Investment
Good output water quality
| Item | HI-UF-100 | HI-UF-2000 | HI-UF-5000 | HI-UF-50000 |
|---|---|---|---|---|
| Size Lxlxh | 200 x 120 x 120 cm | 250 x 150 x 200 cm | 300 x 150 x 200 cm | 1000 x 200 x 240 cm |
| Weight | 0.8 t | 1.2 t | 2.5 t | 8.5 t |
| Ip | 64 (boxed) | 63 (container) | 63 (container) | 63 (container) |
| Power Supply | 1 kVA (400VAC) | 4 kVA (400VAc) | 4 kVA (400VAc) | 12 kVA (400VAc) |
| Prefiltering for high turbity water | Option | included | included | included |
| Solar or hydro power supply | Option | Option | Option | Option |
| UV post treatment | Option | included | included | included |
| Sedimentation tank prefiltering | Option | Option | Option | Option |
| Chlorination unit for effluents | Option | Option | Option | Option |
