Black Water and Waste Water treatment, Water reclamation for irrigation and pondfish

Compact Black water treatment modules based on immersed membrane bioreactor operating system from the MBR process, a unique treatment process designed for municipal and industrial wastewater treatment and reuse applications. The predesigned and skid-mounted system can be offloaded quickly and efficiently at your wastewater treatment site.

The treatment of bio-toilet is based on the membrane bio-reactor technology. It comprises the biological treatment and membrane separation in a single reactor. The biological treatment uses the carbonaceous bacteria to decompose the organic pollutants in incoming wastewater. With the application of membrane separation, the treated wastewater could be separated from bacteria and suspended solids so that the crystal clear effluent could be obtained and the clarification tank for treated effluent could be omitted. Disinfection is being done by ultraviolet (UV) or chlorination.

RO systems for potable water

Item MBR-20 MBR-60 MBR-120
Type MBR Filter MBR Filter MBR Filter
Usage Treatment of black water. Treatment of black water. Treatment of black water.
Treatment Capacity m3/d (m3/h) 20 (1) 60 (3) 120 (6)
Influent MLSS 10'000 mg/l 10'000 mg/l 10'000 mg/l
Output :
Coliform bacteria (with UV/chlorine) < <1 /100ml < <1 /100ml < <1 /100ml
TSS < 10 mg/l < 10 mg/l < 10 mg/l
BOD <5 mg/l <5 mg/l <5 mg/l
COD <30 mg/l <30 mg/l <30 mg/l
PH 6.5 -8.5 6.5 -8.5 6.5 -8.5
Admitted reuse : Irrigation, Pondfish Irrigation, Pondfish Irrigation, Pondfish
Operating temperature 5-55°C 5-55°C 5-55°C

Post treatment water usage : Irrigation, Domestic but non drinking
Type of wastewater treated : Toilets, food processing, grey water

Bio-toilets and MBR modules adopt the membrane bio-reactor (MBR) technology to treat the wastewater. Since the membrane (pore size smaller than 0.1 micron) is submerged inside the biological reactor, all carbonaceous bacteria for decomposing organic pollutants can be retained inside the reactor. Comparing the bacteria content with the traditional biological reactor such as oxidation ditch/ Rotating Biological Contactor, RBC, MBR has 3-4 times higher of bacteria content. The higher the bacteria content, the higher efficiency of the biological reactor. It also results of smaller footprint for the bio-reactor. With the membrane separation, the crystal clear treated effluent can be obtained and it could be re-used as the water for irrigation, floor washing and toilet flushing.

Item MBR-20 MBR-60 MBR-120
Size Lxlxh 400 x 210 x 210cm 600 x 210 x 210cm 800 x 210 x 210cm
Weight 2.6 t 3.5 t 5.2 t
Power Consumption 7 kW 22 kW 35 kW
Solar power supply Option 7 kVA Option 24 kVA Option 40 kVA
HydroPower in river power supply Option 7 kVA Option 24 kVA Option 40 kVA
Sedimentation tank prefiltering Option Option Option
